Features:

• Triple Hammer mechanism reduces vibration and cam-out
• 4-step tightening mode selector
• Newly designed airflow system cools down the motor and hammer case for more durability
• Well-balanced weight distribution for better work efficiency
• Remaining battery indicator

Capacity:
– Bolt: 5 -18 mm
– High Tension Bolt: 5 – 14 mm
– Machine Screw: 4- 10 mm
– Self-Drilling Screw: 3.5 – 6 mm

Drive: 6.35 mm
Tightening Torque : 207 Nm
Battery Voltage : 18 V

No Load Speed
– Power Mode : 0 – 2900 /min
– Normal Mode : 0 – 2900 /min
– Soft Mode : 0 – 900 /min
– Self-Drilling Screw Mode: 0 – 2900 /min

Full Load Impact Rate
– Power Mode : 0 – 4000 /min
– Normal Mode : 0 – 4000 /min
– Soft Mode : 0 – 1900 /min
– Self-Drilling Screw Mode: 0 – 2100 /min

Overall Length : 127 mm
Weight : 1.3 kg
